200W LED High Bay Light with Lumileds 3030 Chips

HANGZHOU ZGSM TECHNOLOGY CO., LTD.
  • Color Temperature：3000K, 4000K, 5000K, 5700K
  • Lamp Body Material：Aluminum Alloy
  • Power：40W
  • Usage：Warehouse
  • Lifespan：100, 000
  • IP Rating：IP66

Base Info

  • Model NO.：ZGSM-GCD200H4
  • Certification：CE, EMC, GS, LVD, RoHS, SAA, UL, Ce, EMC, Energy Star, FCC, GS, RoHS, SAA, Saso, UL
  • Beam Angle：60deg; 90deg; and 110deg;
  • Lumen Output：24000lm(+,-5%)
  • Driver Efficiency：> 90%
  • CRI (Ra>)：Ra >= 70
  • Transport Package：1unit,Carton
  • Specification：CE, ROHS, GS, CB, UL, CUL, DLC
  • Trademark：ZGSM
  • Origin：Lin′an, Hangzhou, Zhejiang, China
  • HS Code：9405409000
  • Production Capacity：50000 PCS,Month

Description

SpecificationsModelZGSM-GCD200H4LED BrandLUMILEDS® LUXEON 3030Driver BrandMeanwell HLG seriesNorminal Wattage200WLED Module Quantity5 modulesInput Voltage100-240/277VACPower Efficiency>90%Power Factor>0.95Lamp Rated Luminous Efficiency>120lm/wLamp Rated Lumen output24000 lm (Lumen tolerance +/- 5%)Color Rendering IndexRa>70Color Temperature3000 4000 5000 or 5700KPhotometric Type60,90,110 degreesOptimal Operating Temperature25ºCStorage Temperatures'-40ºC~+50ºCWorking EnvironmentBetween-40°C~+50°C, 10%~90%RHTotal Harmonic Distortion< 20%Lumen Maintenance> 100000 hours -L70, @25 ºC (77 ºF)Body and Shell MaterialsAnodized AluminumIP RatingIP66 with test reportIK RatingIK10 with test reportCertificationCE,ROHS,GS,CB,UL,cUL,DLC,LM-79,SAAOptional Function1-10V DC or PWM Signal or Resistance DimmingTimer/Photocell ControlWarranty5 years  Packing DetailsFixture Dimension585 x340 x156 mmFixture Weight7.0 kg /15.4 lbsPacking Dimension635 x365 x160 mmPacking Weight8.1 kg /17.9 lbs
