• Model NO.：Rb-Lhb-200W
• Certification：CE, EMC, LVD, RoHS, VDE
• Beam Angle：30,60,90,120,70*140 Degree
• Item No.：Rb-Lhb-200W
• LED：3030 High Brightness LED Chip
• CCT：3000K, 4000K, 5000K, 6000K
• Luminous Flux：26000lm High Lumen LED High Bay
• Material：Aluminum Housing
• IP Rate：IP65 Waterproof Dustproof
• Color Rendering Index：>80
• Working Life-Span：50000 H
• LED Driver：Meanwell Driver LED Highbay Light
• LED Power：200W LED Linear High Bay
• Transport Package：1PCS,Box
• Specification：CE,RoHS
• Trademark：rayborn
• Origin：China
• HS Code：9405409000
• Production Capacity：50, 000PCS,Month

200W Linear LED High bay Light Technical ParametersItem No.:RB-LHB-200WInput Voltage:AC 100-277VFreqency Range:50Hz~60HzLED Chip:3030 ChipPower Driver:Meanwell Power Factor:>0.98Power Efficiency:>93%LED Power200WLED QTY: 558pcsLED Working Voltage:DC 30~36VSystem Consumption:206WLED Luminous FluxWarm White23500LMPure White25000LMCool White26000LMViewing Angle:30/60/90/120/70*140 degreeMaximumIlluminanceHeight 10M185LUXHeight 20M47LUXHeight 30M21LUXIlluminance AreaHeight 10MDia.10.8 M  points visibleHeight 20MDia.21.6M points visibleHeight 30MDia.32.5 M points visibleIlluminance Uniformity:>0.6Color TemperatureWarm White3000K~3500KPure White4500K~5500KCool White6000K~6500KColor Rendering IndexRa>80Light Distribution:LED points visibleLED Junction Temperature:≤115ºCWorking Temperature:-35ºC~55ºCIP Grade:IP65Working Life-span:50000 HPower Line:1.0 mm three lineConnect WireBrownLBlueNYellow / GreenGCertificateCE/SAA /ROHS

Linear LED High bay Lamp Features:
1.IP65, water-proof, dust-proof, moisture-proof.
2.120-130 LM/W .
3.HLG Meanwell dirver with high power factor, flicker free instant re-strike
4.No flicker or buzz
5.4m to 12m application
6. IP65 waterproof, dust-proof, corrossion proof.
7. Profiled aluminum housing and screw locked ends
8. Tempered frosted PC lens, low dazzling
9. Gas-tight silicon rubber seal made for wet locations
10. Aircraft-grade 6063 aluminum housing, quick heat sink and durable.
11. Different beam angle 30/60/90/120/70*140 degree all are available
12. Excellent vibration & shock resistance
13. Environment-friendly, no air pollution, no lead-free, no-mercury.
14. Versatile, trouble-free installation: linkable, rotating, suspended, ceiling.
15. CE,RoHS,VDE approved
16. Apply for unique surface treatment technology, welldecorated, novel style, easy to install, lower maintenance cost and wide in application.

Linear High Bay LED lights Competitive Advantage :
1. CE & RoHS & TUV&SAA approved, Quality Guaranteed
2. Imported original Samsung ,OSRAM led chip, superior light source
3. OEM & ODM welcome, independent R&D ability, patent design.
4. Fast delivery, 2-15 workdays depends on order quantity after payment confirmed
5. Reliable quality & credit, 5 years warranty and 50.000 hours lifespan



Linear LED High bay light details :




Linear LED High bay light Application:
1. Workshop and factory lighting.
2. Goods shelf or corridor lighting.
3. Museum, supermarket ,exhibition hall ,stadium and gymnasium lighting.
4. Highway toll station ,Parking lot ,and gas station lighting.
5. Building and smeltery lighting.



Linear LED High bay light more than 24hours aging test :
All LED lights will be over 24 hours aging tested, inspection department
will test 100% products including light up test , power wattage test ,
highVoltage test , waterproof test , ground connection test and so on,
defective rate is controlled  less than 0.1%. Quality is ensured, you can
be assured.






Linear High bay led light Shipping & Package :

Our individual package maximize protecting the LED lights from transfer damage in transit.
1. Label on backside of each LED lights and your required label is available.
2. One piece led Light per carton , strong and professional package for safety transportation .
3. Clear label Item show what is product in the cartons, including watts, CCT, quantity,etc.

We can also custom color packing and put customer logo on it.

CE/RoHS/SAA Certification:

      We has a group of professional technical R & D team, who can provide the OEM / ODM services according to customers and LED lighting solutions,our factory has passed the authentications of ISO9001:2000,CE, FCC, ROSH ,TUV authentication.

Rayborn Company viewing :
Rayborn Lighting Co.,Ltd is a professional manufacturer ,focus on Industrial LED lights and commerical LED lights research ,devolopment ,production,sales ,on service,was in High-end operation and service provider in High-power led .Under the country "saving "polics,we are striving to create environment protection ,energy saving ,long life lighting and earned a reputation of being a quality supplier of LED lighting .

We has a group of professional technical R & D team, who can provide the OEM / ODM services according to customers and LED lighting solutions,our factory has passed the authentications of ISO9001:2000,CE, FCC, ROSH ,TUV authentication.





Payment terms :
1. Payment: T/T, L/C at sight, Western Union ,Paypal available
2. Samples can be available within 5-7 working days; Order: 10-20Days
3. Shipping freight is quoted under your requests
4. Shipping port:Shenzhen , China
5. Discounts are offered based on order quantities



Our Services :

     As a big led manufacturer with years of experiences,we Rayborn led lghting would very like to be your reliable lighting specialist. We ensure that:

1.Offering you the lowest price with good quality led lights.
2.Delivery the goods to you with speed and precision wherever you are.
3.Reply your inquiry and request in 8 hours during workdays.
4.Keep on researching and developing news prodcuts to satisfy your various needs.



FAQ
1. What is the general business process?
Answer : Send Inquiry to Rayborn. → Specification Confirmation → Quotation → Sample List Confirm → Proforma Invoice → Payment Bank Slip → Sample Delivery → Sample Satisfactory → Bulk Order List → Proforma Invoice → 30% Deposit Payment in Advance → Production Ready → 70% Balance bank slip → Delivery → After Sale Service

2. What is the warranty?
Answer : 5 years warranty is offered depending on different types of lights. If item fails due to quality problem during warranty, we can send new replacement with freight on ours immediately if urgently. Or we prefer to send replacement with next order.

3. What is the payment term?
Answer : For sample order, we can accept T/T, Paypal, West Union, 100% in advance. For bulk order, 30% deposit in advance by T/T, 70% balance before shipping. For very big order, L/C is negotiable

4. Can I add my logo on the product label?
Answer : Yes, but order quantity is requested depending on different lights.

5. I don't know how many Linear Led High bay Light should I use, can you advise?
Answer : Yes, we can offer our professional solution for you, IES file is available if you have the design team.
