LED Square Ceiling Panel Light LED Lighting Corridor Lighting
Changzhou D & Y Electrical Lighting Co., Ltd.- Color Temperature：3000-6000K
- Lamp Body Material：Plastic
- Style：modern
- Shape：Square
- Shade Type：Plastic
- Usage：Supermark, Parks, Warehouse
Base Info
- IP Rating：IP54
- Install Style：Surface Mounted
- Certification：CE
- Voltage：220-240V
- Beam Angle：120
- Product Name：LED Ceiling Lamp
- Material：PC
- Power：8W
- Color Temperature(CCT)：3000-6000K
- MOQ：500PCS
- PF：0.9
- CRI：Ra>80
- Size：200*200*92mm
- Color：Light Grey
- Transport Package：Inner Box and Outside Carton
- Specification：200*200*92mm
- Trademark：OEM
- Origin：China
- HS Code：9405409000
- Production Capacity：1000,15 Days
Description
Input Valtage:220-240V 50/60Hz
Material:PC,Milky cover
CCT:3000K 4000K 6000K
Ra:≥80
Lumen:90lm/w
IP rating:IP54
MOQ:500 pcs
FEATURES
1.Suitable for outside using and in the rate of IP66.
2.Both of cover and housing area in function of mounting.
3.With high quality of PC materials and reach of IP66.
APPLICATION
Car parks,industrial areas,Offices,corridors,Supermark and shops,Bakeries,Storage and etc.
SPECIFICATION
| Model | Power | CCT | Lumen | RA | IP Rating | Dimension |
| DY-3013S | 8W | 3000-6000K | 728lm | RA≥80 | IP54 | 200*200*92mm |
| DY-3013L | 14W | 3000-6000K | 1274lm | RA≥80 | IP54 | 282*282*100mm |
| DY-3014S | 8W | 3000-6000K | 728lm | RA≥80 | IP54 | 200*200*92mm |
| DY-3014L | 14W | 3000-6000K | 1274lm | RA≥80 | IP54 | 252*252*92mm |
| Model | Power | CCT | Lumen | RA | IP Rating | Dimension |
| DY-CL32 | 14W | 3000-6000K | 1400lm | RA≥80 | IP65 | 326*326*100mm |
| DY-CL27 | 8W | 3000-6000K | 760lm | RA≥80 | IP54 | 270*270*95mm |
| DY-CL21L | 10W | 3000-6000K | 950lm | RA≥80 | IP54 | 220*220*58mm |
| Model | Power | CCT | Lumen | RA | IP Rating | Dimension |
| DY-1300R | 15W | 3000-6000K | 1380lm | RA≥80 | IP65 | 300*300*100mm |
| DY-1300RH | 15W | 3000-6000K | 1100lm | RA≥80 | IP65 | 300*300*100mm |
| DY-1300RG | 15W | 3000-6000K | 1100lm | RA≥80 | IP65 | 300*300*100mm |
| DY-1350R | 25W | 3000-6000K | 2300lm | RA≥80 | IP65 | 350*350*100mm |
| DY-1400R | 30W | 3000-6000K | 2800lm | RA≥80 | IP65 | 400*400*100mm |
